DRAKA U/UTP LSOH CAT5e GREY 24AWG 305M FULL COPPER ECA

Model: DRAKA 60011512 (CPR: Eca)

UC300 24 cat.5e U/UTP 4P LSOH

Application:

• Primary (Campus), Secondary(Riser), Tertiary (Horizontal)
• IEEE 802.3: 10Base-T; 100Base-T; 1000Base-T
• IEEE 802.5 16 MB; ISDN; TPDDI; ATM

Standards:

• EIA/TIA 568A;
• ISO/IEC 11801 2nd ed.; IEC 61156-5
• EN 50173; EN 50288-3-1

Flame resistance:

• LSHF(LSOH): IEC 60332-1; IEC 60754-2; IEC 61034

Construction

• Conductor: Bare copper wire Ø 0,5mm (AWG24)
• Insulation: Polyethylene, Ø 0,9mm
• Twisting: 2 cores to the pair
• Cable lay up: 4 pairs to the core
• Sheath: LSHF (FRNC, LSOH), grey RAL 7035

Mechanical properties

• Bending radius:
• installation: 8 x D
• installed : 4 x D
• Temperature range:
• during operation: -20°C to +60°C
• during installation: 0°C to +50°C

Technical data

• Product name: UC300 24 cat.5e U/UTP 4P LSOH
• Cable type: J.2YH 4 x 2 x 0.5
• Outer diameter (mm): 5.0
• Fire load:
• 336 MJ/km
• 0.093 KWh/m
• Weight (kg/km): 36
• Copper content (kg/km): 17,5
• Tensile force (N): 100
• Nominal velocity of propagation NVP (%): 67

Certified

• 3p
