HIKVISION 7″ TOUCH-SCREEN INDOOR STATION 800*480

• Video intercom function


• Remote unlocking function;


• Resident-to-resident audio call


• Live view of HD video


• Voice message function


• Auto- respond and no disturbing mode


• Noise suppression and echo cancellation


• 2-ch zone alarm and SOS calling function


• Community notice


• Convenient installation with the bracket, batch setting, andpower over video/audio distributorConvenient installation with the bracket, batch configuration, and power over video/audio distributor

System Parameters

• Processor High-Performance Embedded SOC Processor


• Operation System: Embedded Linux Operation System

Display Parameters

• Display Screen: 7-Inch Colorful TFT LCD


• Display: Resolution 800 ×480


• Operation Method: Capacitive Touch Screen, Physical Button


• Operation Interface: Flattened UI Operation Interface

Audio Parameters

• Audio Input: Built-in Omnidirectional Microphone


• Audio Output: Built-in Loudspeaker


• Audio Compression Standard: G.711U


• Audio Compression Rate: 64 Kbps


• Audio Quality: Noise Suppression and Echo Cancellation

Network Parameters

• Ethernet: 10M/100M Self-Adaptive Ethernet


• Network Protocol: TCP/IP, SNMP, SIP, RTSP

Alarm Parameters

• Alarm Input: 2-ch Alarm Input Sensor

Device Interfaces

• Network interface: 1 RJ45 10/100 Mbps Self- Adaptive Ethernet Interface

General

• Power Supply: 24 VDC, Power Over Network Cable/12DC


• Power Consumption: =10 W


• Working Temperature -10° C to + 55° C (14° F to 131° F)


• Working Humidity: 10% 90%


• Dimension (L x W x H): 195.8 mm × 132.8 mm × 17.5 mm


• Certification:  FCC, IC, CE, C-TICK, ROHS, REACH, WEEE
